Technical spec
| Xpress Coating System |
|
| Pipe Diameters |
DN32-300 (1¼-12") |
| Max Range |
40m (131') |
| Power |
UK/US: 110V, 15 Amp |
| |
EU: 220V, 16 Amp |
| Weight (empty) |
Pump: 100kg (220 lbs) |
| |
Reel: 50kg (110 lbs) |
| Size (WxLxH) |
Pump: 68x65x147 cm
|
| |
26.9x25.7x58.1"
|
| |
Reel: 59x73x70 cm |
| |
23.3x28.8x27.6" |
| Maxi Pump |
|
| Pipe Diameters |
DN70-300 (3-12") |
| Max Range |
39m (128') |
| Power |
UK/US: 110V, 15 Amp |
| |
EU: 220V, 16 Amp |
| Output (kw) |
0.25 |
| Weight |
23kg (51 lbs) |
| Size |
66 x 43 x 55 cm |
| |
26 x 16.9 x 21.7" |
| Mini Pump |
|
|
Pipe Diameters
|
DN32-200 (1¼-8")
|
|
Max Range
|
22m (75')
|
|
Power
|
UK/US: 110V, 15 Amp
|
| |
EU: 220V, 16 Amp
|
|
Output (kw)
|
0.18
|
|
Weight
|
16kg (35.5 lbs)
|
|
Size
|
41 x 42 x 54.4 cm
|
| |
16 x 16.5 x 21.5"
|
How to use
The Picote Brush Coating™ system is a simple, fast, and practical coating solution used to renovate and prolong the life of stack pipes, drains, sewers, water pipes*, electrical conduits, and more.
Clean the pipe well and apply two coats for a corrosion barrier. Alternatively, apply additional coats of resin to form a new, seamless semi-structural rehabilitation that should last 30-50 years.
The Mini, Maxi or Xpress Coating Pumps can be combined with several different Miller models to meet project needs based on pipe length & diameter.
For pipe coating and degreasing in DN32-300 (1¼-12”) diameter pipes up to 40m (131’) in length.
- Sewers
- Stack Pipes/Vent Stacks
- Drains
- Apartments & High-Rise
- Industrial & Nuclear
- Hydro-Electric
- Residential & Municipal
- Pools & Dams
- Hybrid - CIPP mains/stacks and coat laterals
- Entire Lines - Coat entire piping systems from rooftop to city sewer
- Protection - Coating barrier to prevent rust & corrosion
- Reinforce - Strengthen CIPP lined connections
- Gapping - Fill gaps between CIPP liners
- *DC1000E Epoxy Resin for Mini & Maxi Pump is NSF61.5 Certified for DN100 (4") and larger pipes (final coat in white)
100% Solids Epoxy
ASTM & NSF 61.5 certified. WRc Approved method.
Picote Heater
Decrease time between coats.
Cleaning / Coating Brush
High-quality brush with nylon bristles for brush coating and cleaning PVC pipes
Smart Mixer 2.0
Battery powered (Li-ion battery) cartridge mixer. Comes in carry case with spare battery, charger & 600ml piston
Brush Stopper
Brush Stoppers available for use with Maxi Pump and Mini Pump
Maxi Pump Bracket
Maxi Pump Bracket attaches the Maxi Coating Pump to a Midi Cleaner or Super Midi
Delivery Hose Lubricant
Delivery Hose Lube, to pre-lubricate the inner surface of the Coating Pump Delivery Hose to make pumping faster.
